QuintSonic 7
Features:
- As a result of the sensor-integrated digital 32-bit signal processing (SIDSP®), the measurement signal may be quickly evaluated while maintaining high precision and reproducibility.
- More than 40 measurements each minute: start, wait a second, finish.
- The measurement of small and curved items is possible with a just 5 mm measuring area.
- Zoom-capable graphic displaying individual coats an interface with a menu system and a screen.
Description
Specifications:
| Property | Value |
|---|---|
| Measuring principle | Ultrasonic pulse run-time method |
| Measuring range / Resolution / Accuracy | Nr.1 Measuring range 356 µm Resolution 0,25 µm Accuracy 0,25 µm
Nr.2 Measuring range 890 µm Resolution 0,5 µm Accuracy 0,5 µm Nr.3 Measuring range 1.900 µm Resolution 1 µm Accuracy 1 µm Nr.4 Measuring range 3.900 µm Resolution 2 µm Accuracy 2 µm Nr.5 Measuring range 7.500 µm Resolution 4 µm Accuracy 4 µm (at 2375 m/s ultrasonic velocity in all layers) |
| Minimum layer thickness | approx. 10 µm (depending on the ultrasonic velocity in the layer) |
| Number of layers | up to 5 layers in one operation |
| Measurement cycle time | approx. 1 s |
| Measuring area | 5 mm Ø / 0.2″ Ø |
| Contact area | 10 mm Ø / 0.4″ Ø |
| Minimum curvature radius | convex: 50 mm / 2″ concave: – |
| No. of test series | 300 |
| Measurement storage | 250.000 |
| Measurement units | µm, mm, mils |
| Calibration | Sound velocity calibration for up to 5 layers |
| Statistics | N (number of measurment values) · Minimum · Maximum · Average · Standard · deviation · Coefficient of variation · Block statistics (user adjustable) · Histogram · Trend diagram |
| Interface | Infrared (IrDA® 1.0) USB optional RS-232 via additional adapter cable |
| International Standards | DIN EN ISO 2808 |
| Signal processing | Sensor integrated digital 32-bit signal processing (SIDSP®) |
| Operating temperature | 5 °C – 50 °C / 40 ° F – 122 °F |
| Storage temperature | -10 °C – 50 °C / 14 °F – 122 °F |
| Power Supply | 4 x Mignon battery AA / LR06 Power supply (90 – 240V AC / 48 – 62 Hz) |
| Dimensions | Gauge: 153 mm x 89 mm x 32 mm / 6″ x 3.5″ x 1.3″ Sensor: Ø 25 mm x 60 mm / Ø 1″ x 2.4″ |
| Weight | Gauge: 310 g / 10.8 oz Sensor: 80 g / 2.8 oz Cable: 30 g / 1 oz |
