Ci4200 Compact Benchtop Spectrophotometer

Features:

Find colour and gloss variations as soon as possible using conventional measuring techniques to assure correct colour readings or to confirm visual examination (SPIN/SPEX).
Produces connected 600 gloss values for an ASTM D523 and ISO 2813 compliant, more accurate evaluation of sample gloss.
Manage performance and provide consistency throughout the supply chain regardless of where the instruments are being used with its incorporated NetProfiler.
Enables easy data interchange during the operation with X-Rite portable spectrophotometers like the Ci64.
In addition, samples may be seen and targeted using a sample arm, and LED membrane gives status and operation feedback with remote trigger.

Specifications:

Short Term Repeatability – White	.05 ΔE*ab on white ceramic
Measurement Geometry	d/8°
Inter-Instrument Agreement	0.20 ΔE*ab avg.
Illumination Spot Size	14mm
Lamp Life	Approx. 500,000 measurements
Light Source	Gas-filled tungsten lamp + UV LEDs*
Measurement Cycle Time	≈ 2 seconds
Measurement Spot	8mm
Measurement Time	≈ 2 seconds
Photometric Range	0 to 200%
Photometric Resolution	0.01%
Spectral Analyzer	Blue-enhanced silicon photodiodes
Spectral Interval	10nm
Spectral Range	400nm-700nm
Spectral Reporting	10nm
Reflectance Aperture(s)	1
Humidity	5% to 85%, non-condensing
Operating Temperature Range	50° to 104°F (10° to 40°C)
Storage Temperature Range	‘-4° to 122°F (-20° to 50°C)
Dimensions (length, width, height)	26.4cm, 19.0cm, 22.0cm
Weight	‘5.2kg
Package Dimensions (length, width, height)	48cm, 33cm, 36cm
Shipped Weight	’10kg
Communication Interface	USB 2.0
Software Development Kit	XDS4
Voltage	100-240VAC 50/60Hz, 12VDC @ 2.5A
Warm Up Time	None
Calibration	White, Zero, UV*
Embedded NetProfiler Support	Yes
NetProfiler Support	Embedded
Sample Preview	Targeting window
Service Indicator	Status panel
Transform Support	Embedded
Warranty	12 months
What’s Included?	Instrument with white calibration standard, black trap, green standard, manual(CD), AC adapter, USB cable, UV cal standard*
Windows	N/A
Security	N/A
