MiniTest 650

Features:

Measuring coating thickness between 2 and 3 mm.
For rapid measurements on steel and non-ferrous metals, a universal probe with automated substrate identification is available.
Probe tips that are essentially indestructible and resistant to wear.
USB interface for PC data transmission.
Analysis using statistics of the readings (measurement data).

Specifications:

Property	Value
Measuring range	model F (steel): 0 µm – 3000 µm / 120 mils model N (non-ferrous metal): 0 µm – 2000 µm / 80 mils model FN (dual sensor): 0 µm – 2000 µm / 80 mils
Measuring uncertainty	± (2 % of reading + 2 μm / 0.08 mils)
Minimum curvature radius	5 mm / 0.2“ convex 25 mm /1“ concave
Minimum measuring area	Ø 20 mm / 0.8“
Minimum base thickness	Sensor F: 0.5 mm / 20 mils Sensor N: 50 µm / 2 mils
Display	4-digit screen data (11 mm / 0.44”)
Measuring units	μm – mils, user selectable
Calibration	standard, 1-point and 2-point calibration
Statistics	calculated from maximum 9.999 readings – mean value – standard deviation – number of readings – minimum – maximum
Interface	USB
Power supply	3 Micro AAA batteries (for more than 10,000 readings)
Dimensions and weight	gauge: 70 mm x 122 mm x 32 mm / 2.7” x 4.8” x 1.26” sensor: Ø 15 mm x 62 mm / Ø 0.60” x 2.44”
Weight	225 g
Ambient temperature	gauge: 0 °C – 50 °C / 32 °F – 122 °F sensor: -10 °C – 70 °C / 14 °F – 158 °F
