Ci4100 Compact Benchtop Spectrophotometer

Features:

Quick, precise measurement of samples supplied by the client and other sources.
Complies with ASTM standards and provides associated 600 gloss value to accommodate matte and glossy samples.
The sample arm makes it simple to aim samples for precise readings.
Operators get input on the state and functioning of the instrument through the LED screen, as well as visual indications concerning the need for calibration and whether servicing is required.
With the portable spherical spectrophotometers from X-Rite, there is good inter-instrument agreement.

Specifications:

Short Term Repeatability – White	.10 ΔE*ab on white ceramic
Measurement Geometry	d/8°
Inter-Instrument Agreement	0.30 ΔE*ab avg.
Illumination Spot Size	14mm
Lamp Life	Approx. 500,000 measurements
Light Source	Gas-filled tungsten lamp
Measurement Cycle Time	≈ 2 seconds
Measurement Spot	8mm
Measurement Time	≈ 2 seconds
Photometric Range	0 to 200%
Photometric Resolution	0.01%
Spectral Analyzer	Blue-enhanced silicon photodiodes
Spectral Interval	10nm
Spectral Range	400nm-700nm
Reflectance Aperture(s)	1
Humidity	5% to 85%, non-condensing
Operating Temperature Range	50° to 104°F (10° to 40°C)
Storage Temperature Range	‘-4° to 122°F (-20° to 50°C)
Dimensions (length, width, height)	26.4cm, 19.0cm, 22.0cm
Weight	5.2kg
Package Dimensions (length, width, height)	48cm, 33cm, 36cm
Shipped Weight	’10kg
Communication Interface	USB 2.0
Software Development Kit	XDS4
Status Panel	Yes
Voltage	100-240VAC 50/60Hz, 12VDC @ 2.5A
Calibration	White, Zero
Sample Preview	Targeting window
Service Indicator	Status panel
Transform Support	Embedded
Warranty	12 months
What’s Included?	Instrument with white calibration standard, black trap, manual(CD), AC adapter, USB cable
