SINO – ME01 Sphygmomanometer Calibrator

The ME01 Sphygmomanometer Calibrator is a high-precision pressure calibrator designed for the accurate testing of sphygmomanometers. It integrates a built-in pressure source with a digital pressure transducer, enabling precise measurement and calibration without external adjustments. Compact, portable, and easy to operate, it is ideal for metrology labs, hospitals, and educational institutions.

  • Pressure Range: 0–40 kPa / 0–300 mmHg
  • High Accuracy: 0.05% F.S for reliable calibration
  • Built-in Pressure Source: Automatic pressure generation and adjustment
  • Dual Display Units: kPa and mmHg shown simultaneously

Description

The ME01 Sphygmomanometer Calibrator combines pressure generation and measurement in a single, compact unit. Its built-in high-stability pressure transducer and 24-bit A/D converter ensure precise calibration, automatically compensating for non-linearities and zero drift. The dual-line LCD display allows simultaneous reading in kPa and mmHg, simplifying calibration workflows and improving accuracy.

Designed for laboratories, hospitals, universities, and sphygmomanometer manufacturers, the ME01 supports precise, repeatable calibrations from 0 to 40 kPa (0–300 mmHg). Its F-adjust function enables exact pressure settings, and its lightweight, compact design ensures portability and ease of operation, saving time and labor in routine calibration tasks.

Features

  • Built-in pressure source, easy to pressurize
  • F-adjust function to get the exact pressure value
  • Pressure value can be regulated randomly
  • Pressure units: kPa & mmHg displayed simultaneously
  • Calibrates 0–40 kPa pressure gauges
  • Large LCD with backlight
  • Fast acquisition speed
  • Simple operation, saves labor
  • Compact structure
  • Lightweight

Specifications

Specification Details
Generated Pressure Range 0 ~ 40 kPa / 0 ~ 300 mmHg
Accuracy 0.05% F.S
Working Media Air
Display Double-line large LCD
Pressure Units kPa and mmHg displayed simultaneously
Pressure Transducer Built-in pressure transducer, manual calibration without hardware adjustment
Power Supply 9V DC power adapter, built-in rechargeable lithium battery
Dimensions 145 L × 160 W × 130 H (mm)
Weight 2.2 kg
