Mahr Metrology MarSurf WI 100
High-performance laboratory and QA system
The MarSurf WI 100 is a powerful surface profiler for the three-dimensional measurement and analysis of surfaces – contactless, independent of material, and fast.
High-performance laboratory and QA system
The high-end MarSurf WI 100 instrument features an extended working area in xyz direction for especially large sample volumes: Simply press the side adjustment used to move the additional manual Z-axis and measure the XXL components.
The MarSurf WI 100 is suitable for use in test laboratories and equipped for quality assurance in production environments due to its robust construction.
Typical measuring tasks
- Roughness measurements as per
ISO 4287 & ISO 13565 / ISO 25178 - Topography measurements (including volume, wear, tribology)
- contour and form (2D, 3D)
- pore, particle analysis
- defect detection
| MarSurf WI 100 | Art.-Nr. 6355002 | |
|---|---|
| Resolution | up to 0.2 (nm) vertical |
| Measuring speed | up to 140 fps |
| Measuring principle | White light interferometer High-power LED (650 nm / white) |
| Other | Collision detection in xyz direction |
| Power supplied | 100 – 240 V |
| Surface parameters | ISO 4287, ISO 13565, ISO 25178 … |
