TES Leakage Current Tester CM-03

CM-03

Leakage Current Tester

Product Features

Accurate AC digital clamp meter for leakage current measurement
AC current measurement: 0 ~ 60A
AC voltage measurement: 0 ~ 400V
10μA ultra high resolution on 40mA range
Shield transformer jaws to minimize the effect of external stray magnetic field.
Large jaw with 30 mm diameter.
ACA Five Ranges (40mA, 400mA, 4A, 40A, 60A) for all application.
A filter circuit is designed to eliminate the effect of high frequency noise and harmonics
for AC current measurement.
Large 3 3/4 digits LCD
Fast bargraph display (30 times/sec.) for transient observation.
Continuity and Frequency measurements.
Max/Min, Data Hold functions, and Relative Measurement
Easy single rotary switch for any function selection
600V overload protection for ohm measurement

Category: Clamp Meter

Electrical Specifications: (23℃±5℃)

AC Current:

1 Though the meter can display up to 400A, it is not calibrated beyond 60A.

AC Voltage:(Input Impedance: 10MΩ)

Range

Resolution

Accuracy

Overload Protection

50/60 Hz

40 – 1KHz

400V

0.1V

±1.5%±2dgts

±2.0%±4dgts

AC 800V

Resistance (Ω) and Continuity:(open voltage 0.4V)

Range	Resolution	Accuracy	Beeping	OL Protection
40-400Ω	0.1Ω	±1.0%±2dgts	< 38.0Ω	AC 600V

General Specifications:

Conductor Size:	30mm max. (approx.)
Battery Type:	two 1.5V SUM-3
Display:	3 3/4 LCD with 40 seg. bargraph
Range Selection:	manual
Overload Indication:	OL
Power Consumption:	15 mA (approx.)
Low battery Indication:
Sampling Time:	3 times/sec. (display) 30 times/sec. (bargraph)
Auto-Power-Off:	15 minutes
Operating Temperature:	-10°C to 50°C
Operating Humidity:	less than 85% relative
Storage Temperature:	-20°C to 60°C
Storage Humidity:	less than 75% relative
Altitude:	up to 2000M
Dimension:	210mm (L) x 62.0mm (W) x 35.6mm (H) 8.3″ (L) x 2.4″ (W) x 1.4″ (H)
Weight:	200g (battery included)
Accessories:	Carrying bag x 1 Users manual x 1 1.5V battery x 2 Test leads x 1
