Fungilab – MASTER SERIES EVO Expert
EVO Expert
Innovative equipments with an advanced design and multifunctional viscosity measurements.
- A user-friendly fungilab APP.
- Interface Bluetooth.
- Colour TFT screen for easy readings and fast data recognition.
- Intuitive full-touch keypad: data at your fingertips.
- New USB connection: Type A 2.0 generation for downloading data to the Pc or Pendrive.
- The Bluetooth connection allows the overturned of our experiments to a Tablet.
SCREEN DATA | |
---|---|
Selected speed | rpm |
Selected spindle | SP |
Viscosity reading | cP (mPa·s) or cSt |
Percentatge of full scale | % |
Sample temperature | ºC or ºF |
Shear Rate (with coaxial spindles) | SR (s-1) |
Shear Stress (with coaxial spindles) | SS (N/m2) |
Density (introduced by the user) | g/cm3 |
VISCOSITY READING | |
---|---|
Dynamic viscosity | cP or mPa·s |
Kinematics viscosity | cSt |
Units Converter | from SI to CGS |
PROGRAM FEATURES |
---|
Time to torque: Ending of the test upon reaching a programmed torque |
Time to stop: Ending of the test upon reaching a programmed time |
Multistep: posibility to programme several essays in a successive way |
Ramps: essay programation with an initial and final speed in an specific time |
10 working memories |
OTHER MAIN FEATURES |
---|
AUTO-TEST with visual and resonant alarm |
AUTO-RANGE function |
Temperature Reading through PT100 probe |
User-enabled viscosity and temperature calibration |
6 language options |
Port: USB |
Datalogger: Posibility to tranfer data to a pendrive into Excel format |
Statistics: Posibility to see data in graphics |
Download all data through the bluetooth app |
Spindles
AISI 316 Stainless steel spindle, easily to identify according to its letter and number, in terms of the range of viscosity. Our units fulfills the next standards: These are the standards our units follow: BS: 6075, 5350
- BS: 6075, 5350
- ISO:2555,1652
- ASTM: 115, 789, 1076, 1084, 1286, 1417, 1439, 1638, 1824, 2196, 2336, 2364, 2393, 2556, 2669, 2849, 2983, 2994, 3232, 3236, 3716
Standard delivery
- The equipement is supplied complete with standard spindles
- 4 spindles for L model
- 6 spindles for R and H models
- Viscometer stand
- Spindle protector
- Temperature probe PT100
- Carring case
- USB cable
- External power supply
TECHNICAL SPECIFICATIONS
- Precision: +/- 1% full scale of range
- Resolution: For a minus viscosity of 100 cP : 0.01 cP For a major viscosity of 1000 cP : 0.1 cP For a major viscosity of 5000 cP : 1.0 cP For a major viscosity of 10.000 cP : 5.0 cP For a major viscosity of 25.000 cP : 10.0 cP For a major viscosity of 50.000 cP : 25.0 cP For a major viscosity of 100.000 cP : 100.0 cP For a major viscosity of 1.000.000 cP : 1.000.0 cP
- Repeatability: 0.2%
- Temperature probe features: Temperature limits: -40ºC to 300ºC -40ºF to 572ºF Resolution: 0.1ºC / -17.722 ºF Precision: +/- 0.2ºC / +/- 17.666 ºF Type of probe: PT100
- Supplied at 110-240VAC, 50/60 Hz.
- Software: Fungilab Data Boss The Fungilab Data Boss software complies the FDA 21CFR PART 11 regulation
ACCESSORIES
- APM : Small Sample Adapter with circulation jacket (without TL or TR spindles) Sample volume (6.7 – 13 ml.) Compatible with Brookfield viscometers
- APM/B : Small Sample Adapter without circulation jacket (without TL or TR spindles) Sample volume (6.7 – 13 ml.) Compatible with Brookfield viscometers
- LCP : Low Viscosity Adapter with circulation jacket (with spindle) Sample volume (16 ml.) Compatible with Brookfield viscometers
- LCP/B : Low Viscosity Adapter without circulation jacket (with spindle) Sample volume (16 ml.) Compatible with Brookfield viscometers
- HELDAL : Helix Drive Unit Accessory for measuring non-flowing substances viscosity (with spindles)
- THERMOSPHERE : Temperature control unit up to 300 ºC
CODE | MODEL | MEASURING RANGE (CP) | SPEED (R.P.M) | NUMBER OF SPEEDS |
---|---|---|---|---|
VE320003BT | EVO EXPERT L | *1 – 6.000.000 | 0.01 – 250 | 2600 |
VE320002BT | EVO EXPERT R | 25 – 40.000.000 | 0.01 – 250 | 2600 |
VE320001BT | EVO EXPERT H | 200 – 320.000.000 | 0.01 – 250 | 2600 |
The viscosity range of the equipment is referenced between 0.01 and 100 rpm.
PPR
Fast spindle switch (push plug and release)
CODE | MODEL | MEASURING RANGE (CP) | SPEED (R.P.M) | NUMBER OF SPEEDS |
---|---|---|---|---|
VE321003BT | EVO EXPERT L + PPR | *1 – 6.000.000 | 0.01 – 250 | 2600 |
VE321002BT | EVO EXPERT R + PPR | 25 – 40.000.000 | 0.01 – 250 | 2600 |
VE321001BT | EVO EXPERT H + PPR | 200 – 320.000.000 | 0.01 – 250 | 2600 |
The viscosity range of the equipment is referenced between 0.01 and 100 rpm.
Ranges
- (L) Low viscosity model
- (M) Medium viscosity model
- (H) High viscosity model
Low viscosity : The minimum viscosity when using a ‘L’ range with standard spindles is 10cP. (*) For measurements <10cP, its recommended to use in conjunction with the low viscosity adaptor (LCP or LCP/B)
