Mahr Metrology MarForm MMQ 200
The MMQ 200 is the compact form measuring machine for your production and precision measuring room. It is available in two versions: as a measuring station with the universal T20W measuring probe and as a measuring station with the motorized T7W measuring probe , which, thanks to its unique motorization, enables a further level of automation.
The MMQ 200 is the compact form measuring machine for your production and precision measuring room.
- Proof of shape and position deviations according to DIN/ISO 1101
- fully automatic measurement sequences
- High-precision roundness measuring axis (C)
- Motorized measuring axis vertical (Z)
- Motorized positioning axis horizontal (X)
- Manual tilting and centering table
- Manual length measuring probe T20W or
- Motorized button T7W
- Ergonomic control panel, also allows you to start selected measurement programs (P1, P2, P3)
Motorized probe T7W Roughness
and twist measurements are also possible on the MMQ 200 in combination with the motorized probe T7W.
This makes the MMQ 200 the most universal measuring system in its class and offers an unbeatable price/performance ratio.
| MarForm MMQ 200 | Item No. 5440750 | |
|---|---|
| Roundness deviation (µm+µm/mm measuring height) * | 0.015 + 0.0003 |
| Motorized measurement path Z (mm) | 250 |
| Straightness deviation / 100 mm measuring path (µm)**, Z-axis | 0.15 |
| Straightness deviation / total measuring range (µm)**, Z-axis | 0.3 |
| Parallelism deviation Z / C axis in scanning direction, measuring path (µm) | 0.5 |
| Measurement speed (mm/s), Z-axis | 0.5-30 |
| Positioning speed (mm/s), Z axis | 0.5-100 |
| Roundness deviation (µm+µm/mm measuring height) ** | 0.03 + 0.0006 |
| Axial run-out (µm+µm/mm measuring radius) * | 0.02 + 0.0001 |
| Axial run-out (µm+µm/mm measuring radius) ** | 0.04 + 0.0006 |
| Centering and tilting table | manually |
| Table diameter (mm) | 160 |
| Table load capacity, centric (N) | 200 |
| Speed (1/min) 50 Hz / 60 Hz | 0.2-15 |
| footer text | * Values as maximum deviation from reference circle LSC, filter 15 waves/circumference. ** All values according to DIN ISO 1101 at 20 °C ±1 °C in a vibration-free environment, filter 15 shafts/circumference LSC or 2.5 mm LSS, 5 revolutions 1/min or 5 mm/s and standard stylus arm with ball diameter 3 mm. Proof on the standard including error separation methods. Due to the large number of possibilities, only a few machines are described here as examples. The technical data of “your” MMQ is available from Mahr on request. |
