TES-1393/TES-1394S ElectroMagnetic Field Tester

Product Features

The electromagnetic field radiation levels surrounding power lines, residential appliances, and industrial devices may be measured quickly, accurately, and simply with the help of the EMF tester.
Developed and calibrated to detect electromagnetic field radiation at various bandwidths down to 50Hz/60Hz, the EMF tester is a portable, cost-effective device.
Display milli Gauss and micro Tesla in one tester.
hold function for data.
2000 records can be logged (1393)
99 sets of manual data memory are available (1394S)
Micro-USB connector (1394S)
MicroSD CARD 4GB automatic data memory capacity (1394S)

Specification

Display	Triple LCD display
Range	20/200/2000 milli Gauss 2/20/200 micro Tesla
Resolution	0.01/0.1/1 milli Gauss 0.001/0.01/0.1 micro Tesla
Number of Axis	Triple axis
Band Width	30 Hz to 2000 Hz
Accuracy	20mG/2µT ± (3% + 30d) ±(3%+3d) at 50Hz or 60HZ ±(5%+3d) at 40Hz to 200HZ –3dB at 30Hz to 2000HZ
Over-Input	Display shows “OL”
Auto data memory	microSD CARD 4GB. (1394S)
Sampling Time	Approx. 0.5 second
Battery	6 pcs size AAA (1393 Only Use Alkaline Battery)
Battery Life	Approx. 33 hours (1393) / Approx. 40 hours (1394S)
Operating Temp and Humidity	0℃ to 50℃ (32℉ to 122℉) below 80%RH
Storage Temp and Humidity	-10℃ to 60℃ below 70%RH
Weight	Approx. 165g (1393) / Approx. 225g (1394S)
Dimension	150(L) × 72 (W) × 35(H) mm
Accessories Included	Operation Manual, 6 pcs size AAA. (1393) Operation Manual, 6 pcs size AAA, CD Software, micro-USB Cable. (1394S)
