SUNDOO Torque Meter HP

SUNDOO Torque Meter HP

The HP Series High Impact Torque Meter (1–5000 N·m) delivers high-speed torque testing up to 10,000 rpm, featuring 2000 Hz peak sampling, ±0.5% accuracy, peak hold, GO/NG comparison, unit conversion, and RS-232C data output. Ideal for electric and pneumatic tool calibration.

  • Ultra-Wide Torque Range: Models HP-1 to HP-5000 (1–5000 N·m).
  • High-Speed Testing: Supports up to 10,000 rpm.
  • High Peak Sampling Rate: 2000 Hz for accurate impact capture.
  • High Accuracy: ±0.5% FS or ±1% FS, depending on model.

Share Now:

Facebook Twitter Youtube
Get a Quote

Description

The HP Series High Impact Torque Meter is a sophisticated, multi-purpose instrument specially designed for high-speed and high-impact torque testing. Covering an ultra-wide capacity range from 1 N·m to 5000 N·m, this series is ideal for testing and calibrating electric screwdrivers, pneumatic drivers, torque wrenches, torque screwdrivers, and various fastening tools.
Designed for portability and convenience, the instrument features a compact structure (185 × 110 × 41 mm) and is powered by a rechargeable 8.4 V NiMH battery pack, offering up to 40 hours of continuous operation per charge.
Widely used in the electric power, light industry, machinery manufacturing, and scientific research sectors, the HP Series provides a powerful combination of accuracy, durability, speed capability, and portability.

Features

  • Ultra-Wide Torque Range: Models HP-1 to HP-5000 (1–5000 N·m).

  • High-Speed Testing: Supports up to 10,000 rpm.

  • High Peak Sampling Rate: 2000 Hz for accurate impact capture.

  • High Accuracy: ±0.5% FS or ±1% FS, depending on model.

  • Fine Load Resolution: From 0.0005 N·m to 2 N·m.

  • Peak Hold Function: Capture and hold peak torque, with optional auto-release.

  • GO/NG Comparison: Green/Red indicator lights for pass/fail judgment.

  • LED Display with Blue Backlight: Indicates torque direction clearly.

  • Memory Function: Stores 10 test results and calculates average.

  • Unit Conversion: Automatic switching between N·m, kgf·cm, and lbf·in.

  • RS-232C Output: Data transfer to computer for analysis.

  • Portable Design: Compact size 185 × 110 × 41 mm, weight approx. 2.4–6.4 kg depending on model.

  • Rechargeable Battery: 8.4 V NiMH, approx. 40 hours operation, ≥300 charge cycles.

  • Adjustable Auto Power-Off: Selectable from 1–60 minutes.

Specifications

Model HP-1 HP-2 HP-5 HP-10 HP-20 HP-50 HP-100 HP-200 HP-500 HP-1000 HP-2000 HP-5000
Capacity 1 N·m 2 N·m 5 N·m 10 N·m 20 N·m 50 N·m 100 N·m 200 N·m 500 N·m 1000 N·m 2000 N·m 5000 N·m
Load Resolution 0.0005 N·m 0.001 N·m 0.002 N·m 0.005 N·m 0.01 N·m 0.02 N·m 0.05 N·m 0.1 N·m 0.2 N·m 0.5 N·m 1 N·m 2 N·m
Peak Sampling Frequency 2000 Hz
Testing Speed ≤ 10000 rpm
Power Supply 8.4 V (1.2 V × 7 Nickel-Metal Hydride battery pack)
Charging Time Approx. 4 hours
Battery Operating Time Approx. 40 hours
Standby Time Approx. 3 months
Battery Life ≥ 300 charge cycles
Charger (Adapter) Input: AC 220 V 50 Hz
Output: DC 12 V 300 mA
Accuracy ±0.5% FS ±1% FS
Dimensions (L × W × H) 185 × 110 × 41 mm
Weight Approx. 2.4 kg — Approx. 4.8 kg — Approx. 6.4 kg
