Rhopoint- Gloss Flex 60 Glossmeter

The Rhopoint Gloss Flex 60 is a portable glossmeter for precise surface gloss measurement at a 60° angle. It features fast, repeatable readings, onboard trend analysis, and batch statistics, making it ideal for quality control in coatings, plastics, and other surfaces.

  • Accurate Gloss Measurement: 0–125 GU with 0.1 GU resolution, repeatability ±0.2 GU, reproducibility ±0.5 GU.
  • Fast & Efficient: Quick measurements with user-definable batch names and date/time stamping.
  • Onboard Analysis: Max, min, mean, SD statistics and graphical trend analysis for quality monitoring.
  • Portable & Robust: Rechargeable lithium-ion battery (14,000 readings per charge), compact design (80×150×35 mm), operates 15–40°C with up to 85% non-condensing humidity.

Description

The Rhopoint Gloss Flex 60 Glossmeter is a high-precision instrument for measuring surface gloss, designed for coatings, plastics, and painted materials. It features a 60° measurement geometry with a 6 mm × 12 mm measurement area, providing accurate and repeatable readings with resolution of 0.1 GU. The device offers onboard statistical and graphical analysis, allowing users to monitor Max, Min, Mean, and standard deviation for multiple readings in a batch.

With a full-color, easy-to-read display and 6-button touch interface, the Gloss Flex 60 is user-friendly and supports date- and time-stamped results, pass/fail parameters, and trend analysis. Its rechargeable lithium-ion battery delivers up to 14,000 readings per charge, and its memory stores up to 2,950 readings. Compact and portable, this glossmeter is ideal for quality control, production, and laboratory environments.

Features

  • Simultaneous measurement of all parameters, results are date and time stamped.
  • Displays full statistics for the number of readings in the current batch.
  • Graphical reporting for quick trend analysis.
  • Pass / fail parameters can be defined for instant identification of non-conformances.

Specifications

Specifications:
Instrument Specification
Operation Full colour easy to read screen
Adjustable brightness
6 button touch sensitive interface
Construction Integrated calibration holders for error free calibration
Measurement Fast measurement
Results batching with user definable names
Graphical Analysis On board trend analysis
Statistical Analysis Max, min, mean, S.D.
Power Rechargeable lithium ion – 14,000 readings per charge
Memory 8MB = 2950 readings
Measurement Area 60° 6mm x 12mm
Operating Temperature 15 – 40° C (60 – 104° F)
Humidity Up to 85%, non condensing
Dimensions & Weights Instrument 80 (H) x 150 (W) x 35mm (D), 392g
Measurement head 60 (H) x 110 (W) x 28mm (D),109g
Packed Weight 1.6kg
Packed dimensions 110mm (H) x 280mm (W) x 220mm (D)
Commodity code 9027 5000
GU GUh
Measurement range 0-125 GU 0 -125 GUh (0-12.5 GU)
Resolution 0.1 GU 0.1 GUh (0.01 GU)
Repeatability ±0.2 GU ±0.5 GUh (0.05 GU)
Reproducibility ±0.5 GU ±2.0 GUh (0.2 GU)
Order Codes
Novo-Gloss Flex 60 A4000-020
Customer adaptor (requires drawing of the
part to be measured in .dxf format)
M4000-505
