The MarSurf CM select is a high-performance, configurable confocal microscope that you can use to measure and analyze surfaces three-dimensionally – non-contact, material-independent and fast .
As a multi-sensor system, the MarSurf CM select offers the option of combining different sensor technologies in one measuring device. Depending on the measurement task, the optimum point sensor can also be flexibly selected. The MarSurf CM select meets your individual requirements in terms of sample size, automation, measurement convenience and accuracy – right up to a fully automated measurement solution.
One of our most important criteria means excellent precision, accuracy, repeatability, reproducibility and documentation for traceability and auditability. Our greatest achievement for the customer is a quantitative measurement that they can rely on in the areas of engineering, product and process design, quality control, etc.
| MarSurf CM select | Art.-Nr. 6350006 | |
|---|---|
| resolution | up to 2 (nm) vertical |
| measurement speed | up to 100fps |
| Workpiece weight (max.) in kg | 15 kg |
| Messprinzip | Confocal high power LED (505 nm / white) |
| Languages: | German , English , French , Italian , Spanish , Portuguese , Polish , Russian , Turkish , Chinese , Japanese , Korean |
| Miscellaneous | Collision detection in xyz direction |
| power supply | 100 – 240 V |
| characteristics | ISO 4287, ISO 13565, ISO 25178, … |
Please fill in the request form below and one of our engineers will contact you to discuss your system requirements and if we can help, our typical response time is within 1 – 3 working day.
