Description
The PROVA-6601 AC/DC 2000A Power Clamp Meter is a professional-grade power measurement instrument engineered for precise analysis of electrical systems in industrial and commercial environments. It supports 1-phase and 3-phase (2W, 3W, 3W, 4W) power analysis, delivering True AC+DC power measurement up to 1200 kW (1-phase) and 2000 kW (3-phase) with currents up to 2000A and voltages up to 600V AC / 800V DC. Equipped with True RMS measurement, it ensures accurate readings even under non-linear load conditions, while the auto AC/DC detection and autorange function simplify operation for complex electrical systems.
The PROVA-6601 features a dual 4-digit LCD display that simultaneously presents voltage, current, power (W), power factor (PF), KVA, KVAR, and frequency, providing comprehensive real-time insights. Additional features include phase angle measurement, frequency calculation, low battery warning, overload indication, and memory storage of four records, making it suitable for detailed monitoring, energy audits, and system diagnostics. The clamp meter accommodates large conductors with a 55 mm jaw opening and supports both cable and bus bar measurements, delivering a compact, versatile, and highly reliable solution for professional electrical testing.
Specifications
General Specifications:
| Conductor Size: |
Cable 55mm. (approx.)
Bus Bar 65mm(D) x 24mm(W) |
| Battery Type: |
9V |
| Display: |
2 X 4 Digits Dual Display LCD |
| Range Selection: |
Auto |
| Overload Indication: |
OL |
| Power Consumption: |
25mA (approx.) |
| Low battery Indication: |
|
| Sampling Time: |
0.5 sec. (V and A)
1.6 sec. (W) |
| Operating Temperature: |
4°C to 50°C |
| Operating Humidity: |
less than 85% relative |
| Altitude: |
up to 2000M |
| Storage Temperature: |
-20°C to 60°C |
| Storage Humidity: |
less than 75% relative |
| Dimension: |
271mm (L) x 112mm (W) x 46mm (H)
10.7″ (L) x 4.4″ (W) x 1.8″ (H) |
| Weight: |
647g / 22.8 oz (battery included) |
| Accessories: |
Carrying bag x 1
Users manual x 1
Battery 9V x 1, installed |
Electrical Specifications: (23℃±5℃)
AC+DC True Power: ( PF 0.2 – 1.0, 3Φ3W, 3Φ4W, 1Φ2W, and 1Φ3W)
| Range |
Resolution |
Accuracy(of reading) |
Range |
| 0 – 99.99KW |
0.01KW |
±2.0%±0.05KW |
AC 600V, DC 800V, ACA/DCA 2000A
|
| 100 – 999.9KW |
0.1KW |
±2.0%±0.5KW |
| 1000-1200KW |
1KW |
±2.0%±5KW |
KW Autoranging Map: (PF 0.2 – 1.0, 3Φ3W, 3Φ4W, 1Φ2W, and 1Φ3W)
| |
0V – 200V |
200V – 600VAC, 200V – 800VDC |
| 0A – 200A |
0.00 – 40.00KW |
0.00 – 99.99KW, 100.0 – 160.0KW |
| 200A – 2000A |
0.0 – 400.0KW |
0.0 – 999.9KW, 1000 – 1600KW |
AC+DC Voltage:
(True RMS, Crest Factor<4, Autorange, Overload Protection 800VAC for all ranges.)
| Range |
Resolution |
Accuracy (of reading) |
Input Impedance |
| DC, 50/60 Hz |
40 – 400Hz |
| 0-200V |
0.1V |
±1.5%±5dgts |
±2.0%±5dgts |
10MΩ |
| 200-500V |
0.1V |
±1.5%±5dgts |
±2.0%±5dgts |
10MΩ |
| 500-600V |
1V |
±1.5%±5dgts |
±2.0%±5dgts |
10MΩ |
AC+DC Current: (True RMS, Crest Factor < 4)
| Range |
Resolution |
Accuracy (of reading) |
Overload Protection |
| DC, 50/60 Hz |
40 – 400Hz |
| 0-200A |
0.1A |
±1.5%±5dgts |
±2.0%±5dgts |
AC 3000A |
| 200-500A |
0.1A |
±2.0%±5dgts |
±2.5%±5dgts |
AC 3000A |
| 500-2000A |
1A |
±2.5%±5dgts |
±3.0%±5dgts |
AC 3000A |
AC+DC KVAR: (Reactive Power, 3∅3W, Sine Wave)
| Range |
Resolution |
Accuracy (of reading) |
Range |
| 0 – 99.99KW |
0.01KW |
±2.0%±0.5KW |
AC 600V, DC 800V, ACA/DCA 2000A
|
| 100 – 999.9KW |
0.1KW |
±2.0%±0.5KW |
| 1000-1200KW |
1KW |
±2.0%±5KW |
Frequency: (if < 10 Hz, Hz = 0)
| Range |
Accuracy |
Sensitivity |
| 50/60 Hz |
±2digits |
V: > 1V, A: > 5A |
| 10 – 1000 Hz |
1.5% ± 2 digits |
V: > 1V, A: > 5A |
