S.International- AM-2X2 Radiation Area Monitor

Radiation Area Monitor – AM-2X2 is an advanced and user-friendly system for continuous radiation monitoring in fixed locations, suitable for high-traffic and critical environments.

  • Large LED display with resistive touchscreen for easy operation
  • Supports external scintillation detectors (NaI standard, CsI optional)
  • User-selectable alarms for radiation levels, detector failure, and low battery
  • Network monitoring with software, including email and SMS alerts, with data retained during power loss

Description

One of the most user-friendly, comprehensive, and cutting-edge radiation area monitors on the market is the Radiation Alert® Area Monitor. An clever resistive touch screen display with a large five digit LED readout serves as the user-friendly interface.

An external Sodium Iodide Scintillation Detector is included with the AM-2X2. available probes for cesium iodide. For areas with a lot of traffic, rugged wall-mount enclosure choices are available. Use the free software to keep an eye on each Radiation Alert® Area Monitor on your network. includes user-selectable warning indications for detector failure, low and high radiation alarm levels, and low battery. In order to get alarms while travelling, set up email and SMS alerts. Even in the event of a power outage, all settings are retained inside. The Certificate of Conformance is included with every unit. On demand NIST Source calibrations are available.

Specifications

Applications & Uses

Application Description
Room Monitoring Hospitals, X-Ray rooms, accelerators, laboratories
Portal Monitoring Doors, walkways, access points
Source Monitoring Fixed or mobile radiation sources
Safety Alarms Radiation presence detection or alarm for missing sources

Detector & Performance

Specification Details
Detector 2 × 2 NaI(Tl) Scintillation Probe
Sensitivity > 90,000 CPM/mR/hr (¹³⁷Cs)
Operating Range 0.1 µR/hr – 2 mR/hr (0 – 20 µSv/hr)
Energy Range 30 keV – 2 MeV
Linearity NIST calibrated readings within ±10% of true value (with detector connected)
Response Time Automatically varies from 20 seconds to 2 seconds
Dead Time User adjustable to compensate for detector and electronics

Display & User Interface

Specification Details
Touch Screen Display 4.3″ TFT, 480 × 272 resolution
Color Capability 65K true colors (images, animations, icons, video clips)
LED Display 5-digit LED with 2.5 cm (1 in.) character height
Display Units R/hr, mR/hr, kR/hr, Sv/hr, mSv/hr, µSv/hr, cpm, kcpm, cps, kcps, and others
User Controls Programmable units of measurement with audio & visual alarms

Calibration & Controls

Specification Details
Calibration Access Touch screen push button under calibration cover
Security Secure access for changing calibration and system settings

Indicators & Outputs

Specification Details
Visual Indicators Ultra-bright strobe
Audible Alarm Integrated alarm
Relay Outputs Up to 3 relays via DB-9 serial connection
Data Interface USB VCP for computer data logging
Remote Control Remote software support for alarm indication and acknowledgment (remote silence)

Probe Options

Specification Details
Custom Probes Custom probe options available based on application requirements
