Radiation Alert GammaView

Description

Specifications:

Gamma Scintillator Detector

1×1 NaI Scintillation Probe. 2.5 cm (1 in) dia. x 2.5 cm (1 in) thick with C Connector
The GammaView is optimized for use with the included  1×1 NaI probe.
Please contact us for different probe options.

Operating Range

mR/hr – 1 μR/h to 5 mR/h
μSv/hr – 0.001 to 50
CPM – 0 to approx. 875,000
CPS – 0 to approx. 14,584
Total Counts- 999,999

Energy Range 20 Kev to 1.5 MeV Typical sensitivity 150 CPM/µR/hr.

Accuracy

±10% with Source Calibration (Referenced to Cs137)

Operating Voltage

Typically 500 to 1200 Volts

Selectable Alert Set Range

mR/hr – 1 μR/h to 5 mR/h
μSv/hr – 0.001 to 50
CPM – 1 to 875,000
CPS- 1 to 14,584
Pulsating beeper sounds the alert.

Display

Graphic Display with Backlight

Averaging Periods

Display updates every 3 seconds. At low background
levels, the update is the average for the past 30-second time
period. The timed period for the average decreases as the
radiation level increases.

Anti-Saturation

Meter will hold at OVER RANGE in fields as high as 100 times
the maximum reading.

Outputs

USB for use with Free Observer USB Software for PCs
Bluetooth for use with the Free Observer BLE App for Android.

Count Light

Red LED flashes with each radiation event.

Audio Indicator

Internally mounted beeper (can be switched off for silent operation)

Power Requirements

Two AA alkaline batteries (included). Approx. 500 hrs @ background.

Size

Base unit – 140 X 68 X 33 mm (5.5 X 2.7 X 1.3 in.), Probe- 5.0 X 18.5 cm (2 x 7.3 in)

Temperature Range

-15°C  to +50°C (14°F to 122°F)

Humidity

10% to 70% Non-Condensing.

Weight

Base unit – 193 grams (6.8 oz) with batteries. Probe- 393 grams (13.8 oz)

Includes

NIST Certificate of Calibration, Carrying Case, Xtreme Boot, Stand, Lanyard, Mini-USB Cable, Free Observer USB Software Download, Free Observer BLE Software Download.

Warranty

1 Year Limited Warranty
