Description
Electrical Specifications: (23℃±5℃)
| Type | ℃ | ℉ | ||
| Range | Accuracy | Range | Accuracy | |
| K | -200 ~ -150
-150 ~ -100 -100 ~ 999.9 |
±3.0℃
±2.0℃ |
-328 ~ -238
-238 ~ -148 -148 ~ 999.9 |
±5.4℉
±3.6℉ |
| 1000 ~ 1370 | ±0.1% ±1.0℃ | 1000 ~ 2498 | ±0.1% ±1.8℉ | |
| ±0.2% ±1.0℃ | ±0.2% ±1.8℉ | |||
| J | -200 ~ -100 | -328 ~ -148 | ||
| -100 ~ 100
100 ~ 999.9 |
±2.5℃
±1.5℃ |
-148 ~ 212
212 ~ 999.9 1000 ~ 1832 |
±4.5℉
±2.7℉ |
|
| ±0.1% ±1.0℃ | ±0.1% ±1.8℉ | |||
| ±0.2% ±1℉ | ||||
| E | -150 ~ -100
-100 ~ 760 |
±2.0℃
±0.1% ±1.0℃ |
-238 ~ -148
-148 ~ 999.9 1000 ~ 1400 |
±3.6℉
±0.1% ±1.8℉ |
| ±0.2% ±1℉ | ||||
| T | -200 ~ -150
-150 ~ -100 -100 ~ 400 |
±3.0℃
±0.1% ±1.5℃ |
-328 ~ -238
-238 ~ -148 -148 ~ 752 |
±5.4℉
±0.1%±2.7℉ |
| ±0.1% ±0.5℃ | ±0.1% ±0.9℉ | |||
| R/S | 0 ~ 100
100 ~ 300 300 ~ 999.9 |
±5.0℃
±3.0℃ |
32 ~ 212
212 ~ 572 572 ~ 999.9 |
±9.0℉
±5.4℉ |
| 1000 ~ 1600 | ±0.1% ±2.0℃ | 1000 ~ 2912 | ±0.1% ±3.6℉ | |
| ±0.1% ±2.0℃ | ±0.1% ±3.6℉ | |||
| N | 0 ~ 999.9
1000 ~ 1300 |
±0.1% ±1.0℃
±0.2% ±1.0℃ |
32 ~ 999.9
1000 ~ 2372 |
±0.1% ±1.8℉
±0.2% ±1.8℉ |
| L | -200 ~ 900 | ±0.1% ±1.0℃ | -328 ~ 999.9
1000 ~ 1652 |
±0.1 % ±1.8℉
±0.2 % ±1℉ |
| U | 0 ~ 600 | ±0.1% ±1.0℃ | 32 ~ 999.9
1000 ~ 1112 |
±0.1% ±1.8℉
±0.2% ±1℉ |
| B | 600 ~ 999.9
1000 ~ 1760 |
±0.1% ±2.0℃
±0.1% ±2.0℃ |
1112 ~ 1831
1832 ~ 3200 |
±0.1% ±3.6℉
±0.1% ±3.6℉ |
| C | 0 ~ 999.9
1000 ~ 1760 |
±0.1% ±1.5℃
±0.2% ±1.5℃ |
32 ~ 999.9
1000 ~ 3200 |
±0.1% ±2.7℉
±0.2% ±2.7℉ |
| mV | -10 ~ 60 | ±0.06 mV | -10 ~ 60 | ±0.06 mV |
| mV | -50 ~ -10 | ±0.1 mV | -50 ~ -10 | ±0.1 mV |
General Specifications:
| Battery Type: | 1.5V AA alkaline batteries x 8 |
| AC Adaptor: | DC Regulated 12V / 300mA output
AC 110V or 220V Input |
| LCD | 4.5” STN LCD (240 x 128) |
| Power Consumption: | 100mA (with backlight); 70mA (without backlight) |
| Cold Junction Compensation
Accuracy: |
±0.5℃ / ±0.9℉ |
| Temperature Coefficient: | 0.01% of F.S. / ℃ |
| Isolated Input Protection between
any two inputs: |
350Vp-p |
| Dimension: | 257(L) x 155(W) x 57(H) mm
10.1″ (L) x 6.1″ (W) x 2.2″ (H) |
| Weight: | 1160g / 40.9oz (Batteries included) |
| Operation Environment: | 0℃ ~ 50℃, 85% RH |
| Storage Environment: | -20℃ ~ 60℃, 75% RH |
| Accessories: | 1.5V AA alkaline batteries x 8, AC power adaptor x 1, USB cable x 1, SD card (2GB) x 1,
Carrying bag x 1, User manual x 1, Software CD x 1, Software manual x 1, K-type thermocouples (-50~200℃ / -58 ~392℉±0.75%): 1-meter x 7pcs.; 3-meter x 1pc. |
| Options: | Mini connector for analog Input
Optical RS-232 to USB bridge |
