MSO- Weather Sensor

A rugged, all-in-one weather sensor that measures wind, temperature, humidity, and barometric pressure with reliable accuracy for outdoor monitoring applications.

  • Complete Weather Measurement: Wind speed & direction, temperature, humidity, and pressure in one compact unit.
  • Tough All-Metal Housing: Built for harsh outdoor environments and long-term use.
  • Flexible Outputs: Supports RS-232, RS-485, and SDI-12 with Met One 7500 protocol.
  • Easy Installation: Includes 50 ft integrated cable and mounting, with rain gauge alternative option.

Description

The MSO Weather Sensor is a compact, all-in-one meteorological instrument designed to deliver reliable measurements of wind speed, wind direction, temperature, humidity, and barometric pressure. With a wind speed range up to 50 m/s and precise directional sensing across 360°, the sensor provides dependable real-time weather data at a 1 Hz output rate. Accurate temperature, pressure, and humidity measurements ensure a complete environmental profile, making the MSO ideal for applications that require consistent and trustworthy atmospheric monitoring.

Engineered for durability, the MSO features a tough all-metal housing built to withstand harsh outdoor conditions, operating from −40 °C to +60 °C and up to 100% relative humidity. Flexible communication options—including RS-232, RS-485, and SDI-12 using the Met One 7500 protocol—allow seamless integration with a wide range of data loggers and monitoring systems. Supplied with an integrated cable and mounting hardware, and offering support for rain measurement alternatives, the MSO Weather Sensor is a practical, low-power solution for environmental, industrial, and remote monitoring installations.

Features

  • Wind Direction and Speed.
  • All Metal Housing that is Tough.
  • Temperature.
  • RS232, RS485 and SDI12 outputs.
  • Humidity.
  • Protocol Met One 7500.
  • A barometer’s pressure.
  • 50ft of integrated cable and mounting.
  • Rain Alternative

Specifications

Wind Speed
Range: 0 to 50 m/sec (0 to 112 mph)
Accuracy: ±2% of reading
Resolution: 0.1 m/s
Threshold : 1m/sec
Wind Direction
Range: 0° to 360°
Accuracy: ± 5°
Resolution: 1.0°
Threshold: 1m/sec
Temperature
Range: -40°C to +60°C (-40°F to +140°F)
Accuracy: ±0.4°C
Resolution: 0.1°C
Pressure
Range: 500 to 1100 hPa
Accuracy: ±2 hPa(1)
Resolution: 0.1 hPa
Electrical
Measurement Rate Output: 1 Hz
Signal Output: RS-232C, RS-485, SDI-12

8-36 VDC Supply, 10mA typical

@ 12VDC, option dependent

Environmental
Temperature: 40°C to +60°C (-40 to +140 °F)
Humidity: 0 to 100%
Relative Humidity
Range: 0 to 100%
Accuracy: ±4%(1)
Resolution: 1.0%
Notes:

1. At 25°C
