Description
Specifications:
| Property | Value |
|---|---|
| Measuring range | F: 0 mm – 3 mm N: 0 mm – 2,5 mm |
| Measuring principle | magnetic-induction/eddy currents |
| Signal processing | Sensor integrated 32-bit signal processing (SIDSP®) |
| Accuracy | ± (1.5 μm + 3% of reading) with 1-point calibration ± (0.06 mils + 3% of reading) with 1-point calibration
± (1.5 μm + 2% of reading) with 2-point calibration2 ± (0.06 mils + 2% of reading) with 2-point calibration2 |
| Repeatability | ± (1 μm + 1% of reading) / ± (0.04 mils + 1% of reading) |
| Low range resolution | 0,5 µm |
| Minimum curvature radius convex | 5 mm |
| Minimum curvature radius concave | 40 mm |
| Minimum substrate thickness | F: 0,5 mm N: 0,04 mm |
| Measuring units | metric/imperial switchable |
| Calibration | standard, 1-point and 2-point calibration |
| Statistics | n, x, s, Min, Max |
| Operating temperature | -10 °C – 60 °C 14 °F – 140 °F |
| Storing temperature | -20 °C – 70 °C -4 °F – 158 °F |
| Power supply | 1x AA (Mignon)-Battery |
| International standards | DIN EN ISO 1461, 2064, 2178, 2360, 2808, 3882, ASTM B 244, B 499, D7091, E 376 |
| Dimensions | approx. 157 mm length, Ø 27 mm; 5.2″ length, Ø 1.06″ |
| Weight | ~ 80 grams, 2.8 oz |
