Description
| Precimar CIM 1000 CNC | Art.-No. 5350701 | |
|---|---|
| Measuring range outdoor measurement [mm] | 0 to 1000 |
| Table surface (A x B) mm | 150 X 350 |
| Measuring range internal measurement [mm] | 0.5 to 845 |
| Direct measuring range [mm] | 300 |
| Position deviation / MPE (L in mm) [μm] * | ≤ (0.04+ L/2000) |
| Length measurement deviation MPEE1 (L in mm) [μm] | ≤ (0.055 + L/1500) |
| Measuring forces [N] | 0 to 13.9 |
| Repeatability [μm] | ≤ 0.03 |
| Probing speed with joystick (max) | 8 mm/s |
| Device length [mm] | 2500 |
| Mass [kg] | 840 |
