Fungilab – VISCOLEAD SERIES ONE

Measuring of advanced viscosity. Easy to use. 2 years of garantee

Main Features

SCREEN DATA
Selected speed	rpm
Selected spindle	SP
Viscosity reading	cP (mPa·s)
Percentatge of full scale	%
Sampling temperature	ºC or ºF

VISCOSITY READING
Dynamic viscosity	cP or mPa·s
Units Converter	from SI to CGS

OTHER MAIN FEATURES
AUTO-TEST with visual and resonant alarm
AUTO-RANGE function
User calibration viscosity enabled
10 language options

Spindles

AISI 316 Stainless steel spindle, easily to identify according to its letter and number, in terms of the range of viscosity. Our units fulfills the next standards: These are the standards our units follow: BS: 6075, 5350

BS: 6075, 5350
ISO:2555,1652
ASTM: 115, 789, 1076, 1084, 1286, 1417, 1439, 1638, 1824, 2196, 2336, 2364, 2393, 2556, 2669, 2849, 2983, 2994, 3232, 3236, 3716

Standard delivery

The equipement is supplied complete with standard spindles
- 4 spindles for L model
- 6 spindles for R and H models
Viscometer stand
Spindle protector
Carring case

TECHNICAL SPECIFICATIONS

Precision: +/- 1% full scale of range
Resolution: For a minus viscosity of 10.000 cP : 0.1 cP For a major viscosity of 10.000 cP : 1 cP With the low viscosity adapter (LCP-LCP/B) : 0.01cP
Repeatability: 0.2%
Supplied at 110-240VAC, 50/60 Hz.

ACCESSORIES

APM : Small Sample Adapter with circulation jacket (without TL or TR spindles) Sample volume (6.7 – 13 ml.) Compatible with Brookfield viscometers
APM/B : Small Sample Adapter without circulation jacket (without TL or TR spindles) Sample volume (6.7 – 13 ml.) Compatible with Brookfield viscometers
LCP : Low Viscosity Adapter with circulation jacket (with spindle) Sample volume (16 ml.) Compatible with Brookfield viscometers
LCP/B : Low Viscosity Adapter without circulation jacket (with spindle) Sample volume (16 ml.) Compatible with Brookfield viscometers
HELDAL : Helix Drive Unit Accessory for measuring non-flowing substances viscosity (with spindles)
THERMOSPHERE : Temperature control unit up to 300 ºC

CODE	MODEL	MEASURING RANGE (CP)	SPEED (R.P.M)	NUMBER OF SPEEDS
VL100003	ONE L	*1 – 2.000.000	0.3 – 100	18
VL100002	ONE R	100 – 13.000.000	0.3 – 100	18
VL100001	ONE H	200 – 106.000.000	0.3 – 100	18

PPRFast spindle switch (push plug and release)

CODE	MODEL	MEASURING RANGE (CP)	SPEED (R.P.M)	NUMBER OF SPEEDS
VL101003	ONE L + PPR	*1 – 2.000.000	0.3 – 100	18
VL101002	ONE R + PPR	100 – 13.000.000	0.3 – 100	18
VL101001	ONE H + PPR	200 – 106.000.000	0.3 – 100	18

Ranges

(L) Low viscosity model
(M) Medium viscosity model
(H) High viscosity model

Low viscosity: The minimum viscosity when using a ‘L’ range with standard spindles is 10 cP * For measurements < 10cP, its recommended to use in conunction with the low viscosity adapter (LCP or LCP/B)
