Obsnapmeter- Viscosity Cups AFNOR

The AFNOR Viscosity Cup is a laboratory instrument used to measure the viscosity of paints, lacquers, and other liquids. Made from titanium anodized aluminum, it provides reliable and consistent viscosity testing when used with a stand.

  • Laboratory Viscosity Testing – Used to measure the viscosity of paints, lacquers, and liquids.
  • Durable Material – Made from titanium anodized aluminum for corrosion resistance and durability.
  • Multiple Cup Sizes – Available in 2.5, 4, 6, and 8 AFNOR flow cup sizes.
  • Precision Manufacturing – Each cup has a unique engraved serial number and is produced under strict quality control.

Description

The Obsnapmeter AFNOR Viscosity Cups are precision laboratory instruments designed for measuring the viscosity of paints, lacquers, and other liquid coatings. Manufactured from titanium anodized aluminum, these cups provide durability, corrosion resistance, and consistent measurement performance. They are typically used with a laboratory stand and are suitable for quality control and testing applications in coating and chemical industries.

The cups are designed with a deep overflow well around the top to catch excess liquid during testing and prevent spillage. Their smooth internal structure eliminates hard-to-clean recesses, making maintenance easy and ensuring reliable results. Each cup is produced under strict quality control procedures and engraved with a unique serial number for traceability. Available models include AFNOR 2.5, 4, 6, and 8, allowing users to select the appropriate cup size for different viscosity ranges.

Features

  • A relatively deep well surrounding the top of the cup serves to catch any overflow.
  • The design of the cup and orifice eliminate hard to clean recesses.
  • The outside dimensions have been chosen to support the TQC stands.
  • TQC viscosity cups are made under the continuing quality control procedures.
  • Each cup is provided with an engraved unique serial number.

Specifications

Cup material Titanium anodized aluminum
Weight 271 g
Max. Width 85mm
Height 75mm
ORDERING INFORMATION

Art. No. VF2195
TQC Afnor 2.5 Viscosity flow cup

Art. No. VF2196
TQC Afnor 4 Viscosity flow cup

Art. No. VF2197
TQC Afnor 6 Viscosity flow cup

Art. No. VF2198
TQC Afnor 8 Viscosity flow cup
