Description
The Obsnapmeter Viscosity Cup DIN 53211 is a precision instrument designed to measure the viscosity of paints, lacquers, and other fluid materials in laboratory and quality control environments. Manufactured from titanium anodized aluminum (100 cc capacity) with a stainless steel nozzle retainer, the cup complies with DIN 53211 standards (standard 4 mm orifice, with other sizes similar to DIN 53211). Its interchangeable nozzle system allows flexible viscosity testing across a wide range of flow characteristics, making it suitable for different coating formulations and testing requirements.
Designed for durability and ease of use, the cup features a deep overflow well to catch excess material and a smooth construction that eliminates hard-to-clean recesses. With a weight of 226 g, maximum width of 84 mm, and height of 74 mm, it is compatible with TQC stands for stable operation. Each unit is manufactured under strict quality control procedures and engraved with a unique serial number for traceability. Optional calibration with certified oils is available to ensure measurement accuracy and compliance with quality standards.
ORDERING INFORMATION
Art. No. VF2020
TQC Viscosity Cup DIN 53211 with Interchangeable Nozzle
Type: made of anodised aluminum, to be used with interchangeable nozzles. Complete with stainless steel nozzle retainer. Nozzles to be orderded seperately are listed below.
Art. No. VF2181
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 1 mm (Similar to DIN 53211)
Art. No. VF2022
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 2 mm (Similar to DIN 53211)
Art. No. VF2023
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 3 mm (Similar to DIN 53211)
Art. No. VF2024
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 4 mm
Optional: possible to certify by calibration with certified oils
Art. No. VF2025
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 5 mm (Similar to DIN 53211)
Art. No. VF2026
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 6 mm (Similar to DIN 53211)
Art. No. VF2027
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 7 mm (Similar to DIN 53211)
Art. No. VF2028
TQC Interchangeable Nozzle for Viscosity Cup VF2020, orifice Ø 8 mm (Similar to DIN 53211)
