Description
SPECIFICATIONS:
Accuracies ±(…% of reading +…digits) at 23°C±5°C and below 80%RH
AC Voltage
AC conversions are ac-coupled and valid from 3% to 100% of range
| Range | Resolution | Accuracy | |||||
| 45 – 65 Hz
|
15 – 200 Hz | 200 – 440Hz | 400 – 1kHz | 1 – 5kHz | 5 – 20kHz | ||
| 999.9mV | 0.1mV | ±(0.7%+4) |
±(1.0 % + 4) |
±(2%+4) | ±(2%+20)
[1] |
||
| 9.999V | 0.001V | ||||||
| 99.99V | 0.01V |
±(0.7%+2) |
±(2%+4)
[2] |
Unspecified | |||
| 999.9V | 0.1V | Unspecified | |||||
|
VFD
|
±(1.0%+4) |
+1.0%+4
-0.6%-4 [3] |
Unspecified |
Unspecified |
Unspecified |
||
[1] Below 10% of range, add 12 counts
[2] Frequency range: 1 to 2.5kHz
[3] Specifications increases from -1% to -6% at 440Hz when filter is used
DC Voltage, Conductance, and Resistance
| Function | Range | Resolution | Accuracy |
| mV dc | 999.9mV | 0.1mV | ±(0.1% + 1) |
|
V dc |
9.999V | 0.001V |
±(0.05% + 1) |
| 99.99V | 0.01V | ||
| 999.9V | 0.1V | ||
|
Ω |
999.9Ω | 0.1Ω | ±(0.2% + 2) [2] |
| 9.999kΩ | 0.001kΩ |
±(0.2% + 1) |
|
| 99.99kΩ | 0.01kΩ | ||
| 999.9kΩ | 0.1kΩ | ||
| 9.999MΩ | 0.001MΩ | ±(2% + 1) | |
| 50.00MΩ | 0.01MΩ | ±(5% + 1) [1] | |
| nS | 99.99nS | 0.01nS | ±(5% + 10) [1,2] |
[1] Add 0.5% of reading when measuring above 30MΩ in the 100MΩ range, and 20 counts below 33nS in the 100nS range
[2] When using the rel function to compensate for offers. Smart Ω: ±(1% + 2)
Temperature
| Thermocouple Type | Range | Accuracy |
| K | -40 to 1372°C (-40 to 2502 °F) |
±1.0%±1°C(2°F) |
| J | -40 to 1200°C (-40 to 2192 °F) |
[1] Does not include error of the thermocouple probe
[2] Accuracy specification assumes ambient temperature stable to ±1°C. For ambient temperature changes of ±5°C, rated accuracy applies after 2 hours.
AC Current (45Hz to 10kHz)
| Function | Range | Resolution | Burden Voltage | Accuracy |
| µA ac | 999.9 µA | 0.1 µA | 100 µV/ µA |
±(1.0% + 2) |
| 9999 µA | 1 µA | 100 µ µA/ µA | ||
|
mA ac |
99.9mA | 0.1mA | 3.6mV/mA | |
| 400.0mA | 0.1mA | 3.6mV/mA | ||
| A ac | 9.999A | 1mA | 50V/A |
AC conversions is true rms responding, and valid from 3% to 100% of range, except 400mA range.
(5% to 100% of range) and 10A range (15% to 100% or range).
Capacitance
| Range | Resolution | Accuracy |
| 10.00nF | 0.01nF | ±(2.0% + 2) [1] |
| 100.0nF | 0.1nF | |
| 1.000µF | 0.001µF |
±(2.0% + 2) |
| 10.00µF | 0.01µF | |
| 100.0µF | 0.1µF | |
| 9999µF | 1µF | |
| [1] With a film capacitor or better, using the rel mode to zero residual. | ||
Diode
| Range | Resolution | Accuracy |
| 2V | 0.001V | ±(1.0% + 1) |
3ϕ Phase Sequence Indication
| Range | Frequency Response | Overload Protection |
| 80V to 480V | 50Hz/60Hz | 1000V |
Frequency Counter Sensitivity
| Input Range | Approximate Voltage Sensitivity (rms sine wave) [1] | |
| 5Hz to 100Hz | 100Hz to 100kHz | |
| 999.9mV | 50mV [VFD] | 50mV |
| 9.999V | 500mV [VFD] | 500mV |
| 99.99V | 5V [VFD] | 5V |
| 999.9V | 50V [VFD] | 50V |
| Input Range | Approximate Current Sensitivity (rms sine wave) | |
| 5Hz to 100Hz | 100Hz to 10kHz | |
| 999.9 µF | 50 µF [VFD] | 50 µF |
| 9999 µF | 500 µF | 500 µF |
| 99.99mA | 5mA [VFD] | 5mA |
| 400.0mA | 50mA | 50mA |
| 9.999A | 1A [VFD] | 1A |
| [1] Maximum input = 10 x range (1000V maximum, 2 x10^7 V-Hz product maximum)
[VFD]: Enabled Low Pass Filter |
||
Hz Logic Level Frequency
| Range | Sensitivity |
| 5Hz to 9999Hz | 3.0Vp square wave |
