TES PROVA-131 Multifunction Process Calibrator + DMM

TES PROVA-131 Multifunction Process Calibrator + DMM

Handheld multifunction process calibrator with 4–20 mA sourcing, voltage and frequency measurement, temperature calibration, and HART compatibility. Ideal for industrial and field applications.

  • Source 4–20 mA, 0–20 mA, and 0–24 mA with 1 µA resolution
  • Voltage source: 0–12 V DC, 0–100 mV DC
  • AC/DC mA measurement with True RMS
  • Frequency source and measurement up to 39.999 MHz

Share Now:

Facebook Twitter Youtube
Get a Quote

Description

The handheld multifunction process calibrator is designed for accurate and reliable testing in industrial and field environments. It can source 4–20 mA, 0–20 mA, and 0–24 mA signals with 1 µA resolution. The device also sources DC voltage from 0–12 V and 0–100 mV and supports simultaneous measurement of AC/DC current and voltage with True RMS.

It offers frequency sourcing and measurement from 1 Hz up to 39.999 MHz and calibrates 11 types of thermocouples. Users can also measure resistance, continuity, and diode voltage safely with overload protection. The calibrator supports HART communication with a selectable 250 Ω resistor, allowing smooth integration with HART-enabled devices. Auto ramp and step functions streamline mA, voltage, and temperature testing. The device provides clear warnings for overload, open output, or short circuits, ensuring safe operation.

Features

  • Dimension: 214 × 98.7 × 56 mm (8.4″ × 3.9″ × 2.2″)

  • Weight: 650 g (batteries included)

  • Operating temperature: 0–50 °C, <85% RH

  • Storage temperature: –20–60 °C, <75% RH

  • Accessories: carrying case, user manual, 1.5 V AA ×5, K-type thermocouples (dual plug), alligator clips ×2, test leads ×2

  • DC mA source: 4–20 mA, 0–20 mA, 0–24 mA, resolution 1 µA, accuracy ±0.05% ±8 µA

  • Displays “OL” when output is open

  • DC voltage source: 0–100 mV, 0.1–1 V, 1–12 V, resolution 10 µV–1 mV, accuracy ±0.05%

  • Displays “OL” on short circuit

  • AC mA measurement (True RMS): 24 mA, resolution 1 µA, accuracy ±1–2%

  • DC mA measurement: 24 mA, resolution 1 µA, accuracy ±0.05%

  • DC voltage measurement: 2.4 V–600 V, resolution 0.1 mV–100 mV, accuracy ±1–1.5%

  • AC voltage measurement (True RMS): 24 V–600 V, resolution 1 mV–100 mV, accuracy ±1–2%

  • Frequency source: 1 Hz–20 kHz, resolution 0.1–1 Hz, accuracy 0.1–10 Hz

  • Frequency measurement: 1 Hz–39.999 MHz, resolution 0.001 Hz–1 kHz, accuracy ±0.5%

  • Duty cycle measurement/source: 1–99%, resolution 1%, accuracy ±1% ±30 µs

  • Temperature thermocouple calibration: 11 types, resolution 0.1 °C / 0.1 °F, internal cold junction compensation

  • Resistance measurement: 400 Ω–40 MΩ, resolution 0.01 Ω–1 kΩ, accuracy ±1–1.5%

  • Continuity measurement: open voltage 2 V, <10 Ω beep, overload protection AC 600 V

  • Diode measurement: 0–1.9999 V, resolution 0.0001 V, accuracy ±2.5%

  • Sources mA, V, frequency, sine/square/triangular wave, temperature simultaneously

  • Supports HART communication with selectable 250 Ω resistor

  • Auto step and auto ramp for mA, voltage, and temperature

  • Programmable 0–100% increment/decrement steps

  • Overload, open output, and short-circuit warnings

  • Battery level indicator

  • Clear and user-friendly interface

Specifications

General Specifications:

Dimension 214.0 (L) x 98.7(W) x 56.0(H) mm

8.4″ (L) x 3.9″ (W) x 2.2″ (H)
Weight 650g / 22.9oz (batteries included)
Operation Environment 0℃ ~ 50℃

< 85% RH
Storage Environment -20℃ ~ 60℃ , <75% RH
Accessories Carrying case x 1 User manual x 1

1.5V SUM-3 Battery x 5

K-type thermocouples (dual plugs) x 1 Alligator clips x 2 (black and red)

Test leads x 2 (black and red)

Electrical Specifications:(23+/- 5℃, 10 minutes after turning on the power)

DCmA SOURCE (Max. load 1K, Max. voltage supply 24V)

Range Resolution Accuracy
4 – 20mA, 0 – 20mA, 0 – 24 mA 1µA ± 0.05% ±8µA

When output open, the LCD displays “OL”.

DCmV, DCV SOURCE (Max. load 1mA, Short circuit protection＜100mA）

Range Resolution Accuracy
0 – 100mV 10µV ± 0.05% ± 30µV
0.1 – 1.0000V 100µV ± 0.05% ± 300µV
1 – 12.000V 1mV ± 0.05% ± 3mV

When output short circuit, the LCD displays “OL”.



ACmA MEASURE (Ture RMS)

Range Resolution Accuracy
50/60Hz 40-1KHz
24mA 1µA ±1%±5dgts ±2%±5dgts



DCmA MEASURE

Range Resolution Accuracy
24mA 1µA ±0.05%±2dgts



DCV MEASURE (Overload protection AC 600V, Input impedance 10MΩ)

Range Resolution Accuracy
2.4V 0.1 mV



±1%±3dgts
24V 1 mV
240V 10 mV
600V 100mV ±1.5%±3dgts



ACV MEASURE (Ture RMS)

(Overload protection AC 600V, Input impedance 10MΩ)

Range Resolution Accuracy
50/60Hz 40-1KHz
24V 1 mV ±1%±5dgts



±2%±5dgts
240V 10 mV ±1%±5dgts
600V 100mV ±1.5%±5dgts



Frequency SOURCE (TTL, Square wave)

Range (Hz) Resolution Accuracy
1.0~1000.0Hz 0.1Hz 0.1Hz
1000~10000Hz 1Hz 1Hz
10000~20000Hz 1Hz 10Hz



Frequency MEASURE (Sensitivity RMS 1V)

Range (Hz) Resolution Accuracy
1.000~39.999Hz 0.001Hz ±0.5%±0.003Hz
40.00~399.99Hz 0.01Hz ±0.5%±0.03Hz
0.4000K~3.999KHz 0.1Hz ±0.5%±0.3Hz
4.000K~39.999KHz 1Hz ±0.5%±3Hz
40.00K~399.99KHz 10Hz ±0.5%±30Hz
0.4000M~3.999MHz 1KHz ±0.5%±3KHz
4.000M~39.999MHz 1KHz ±0.5%±3KHz



Duty Cycle SOURCE/MEASURE (1~20KHz）

Range Resolution Accuracy
1% to 99% 1% ±1%±30μS

Temperature Thermocouples

(SOURCE and MEASURE, 0.1C & 0.1F Resolution, Internal Cold Junction Compensation, thermocouples accuracy not included, 3 minutes after plugging in thermocouples.)



°C °F
Range Accuracy Range Accuracy
K -200 to -150 2.0 -382 to -238 3.6
-150 to 0 1.2 -238 to 32 2.1
0 to 1000 0.8 32 to 1832 1.4
1000 to 1370 1.2 1832 to 2498 2.1
J -200 to -150 2.0 -382 to -238 3.6
-150 to 0 1.0 -238 to 32 1.8
0 to 1050 0.7 32 to 1922 1.2
E -200 to -150 1.5 -382 to -238 2.7
-150 to 0 0.9 -238 to 32 1.6
0 to 850 0.7 32 to 1562 1.2
T -200 to -150 1.5 -382 to -238 2.7
-150 to 0 1.2 -238 to 32 2.1
0 to 400 0.8 32 to 752 1.4
R 0 to 500 1.8 32 to 932 3.2
500 to 1760 1.5 932 to 3200 2.7
S 0 to 500 1.8 32 to 932 3.2
500 to 1760 1.5 932 to 3200 2.7
N -200 to 0 1.5 -328 to 32 2.7
0 to 1300 0.9 32 to 2372 1.6
L -200 to 0 0.9 -328 to 32 1.6
0 to 900 0.7 32 to 1652 1.2
U -200 to 0 1.1 -328 to 32 1.9
0 to 600 0.7 32 to 1112 1.2
B 600 to 800 2.2 1112 to 1472 3.9
800 to 1000 1.8 1472 to 1832 3.2
1000 to 1820 1.4 1832 to 3308 2.5
C 0 to 1800 1.0 32 to 3272 1.8
1800 to 2310 1.5 3272 to 4190 2.7

Resistance (Ω) MEASURE  (Open voltage 0.4V, Overload protection AC 600V)

Range Resolution Accuracy
400Ω 0.01Ω





±1%±2dgts
4KΩ 0.1Ω
40KΩ 1Ω
400KΩ 10Ω
4MΩ 100Ω

±1.5%±2dgts
40MΩ 1KΩ

Continuity MEASURE:

Open voltage 2V, Overload protection AC 600V, <10Ω Beep.

Diode MEASURE  (Open voltage 2V, Overload protection AC 600V)

Range Resolution Accuracy
0~1.9999V 0.0001V ±2.5%±5dgts
