Description
Specification:
TEMPERATURE
• Range: -50 °C to +70 °C (-58 °F to +158 °F)
• Accuracy(1): Digital: ±0.2 °C
Analog: ±0.2 °C, +/-1 mV
• Resolution: 0.01 °C
RELATIVE HUMIDITY
• Range: 0 to 100 %
• Accuracy(1): Digital: ±2 %
Analog: ±2 %, +/-1 mV
• Resolution: 0.1 %
PRESSURE
• Range: 500 to 1100 mbar (14.8 inHg to 32.5 inHg)
• Accuracy(1): Digital: ±0.5 mbar
Analog: ±0.5 mbar, +/-1 mV
• Resolution: 0.01 mbar
ELECTRICAL
• Measurement Rate: 1 Hz
• Data Storage: None
• Standard Signal Output: RS-232C, SDI-12 , RS-485, 0-2.5 VDC
• Optional Signal Output: 0-1 VDC, 0-5 VDC
• Power Supply: 9-36 VDC, 25 mA typical @ 12 VDC
ENVIRONMENTAL
• Temperature: -50 °C to +70 °C
• Humidity: 0 to 100 %
PHYSICAL
• Diameter: 7 in (178 mm)
• Length: 8 in (203 mm)
• Weight: 5 lb (2.3 kg)
(1) At 25°C
