SINO HS620 Automatic Pressure Calibrator

SINO HS620 Automatic Pressure Calibrator

Great performance DSP servo control technology, a modular design, and high stability are used in the HS620 Automatic Pressure Calibrator. In conjunction with an intelligent pressure calibrator, this achieves the automatic calibration function for pressure switches. It may automatically safeguard the internal pressure system and self-test for pressure leaks.

Users are instructed on how to calibrate pressure instruments by means of a large touch screen, a user-friendly English interface, and an internal help menu. With the addition of a powerful safeguard function, the items will cease producing pressure when the set pressure values exceed the pressure range. Calibration data are automatically stored, and the calibration results are counted. History information is easily accessed. Driver inside is currently automatically protected.

  • Pressure range: Differential (-1 to 1) bar
  • Gauge pressure (0.1 bar) and (0.95 bar)
  • Air is the working medium.

Share Now:

Facebook Twitter Youtube
Get a Quote

Description

Technical Specification
◆ Pressure range:  Differential (-1~1)bar
Gauge pressure (-0.1~1)bar
(-0.95~25)bar
◆ Working medium: Air
◆ Pressure-control stability: ±0.01%F.S
◆ Noise detection:  ≤40dB(decibel)
◆ Weight: 6.0kg
◆ Dimension: 298L×223W×119H (mm)
◆ Automatic pressure-stability time: ＜ 10s
◆ Fluctuation of servo control:  superior to 0.005%F.S

Functions
HS620 is strictly in accordance with the instrument calibration procedures during operation. it is an ideal automatic pressure calibrator for periodical, mass and repeat calibration work in industrial enterprises. It can be widely used in power, chemical, petrol, metallurgy, metering, military industry, etc.

Characteristics
◆2 minutes :  Easily accomplish single cycle 7 points pressure transmitter calibration
◆7 inch LCD : English interface ,reading precision
◆60 group data : Providing inquiry of record, export data
