Rhopoint IQ 206085 Gloss Haze DOI Meter

Rhopoint IQ 20/60/85 Gloss Haze DOI Meter

Features:

Gloss metre for matt to mirror finishes: 20/60/85°.
As per ASTM E430, measure haze.
Comprehensive statistical analysis and trend graphs.
For simple non-conformance detection, use Pass/Fail.

Categories: Coating / Paint Testing, Gloss/DOI/Haze Appearance Tester

Specifications:

20° Gloss
Range	0 – 100 GU	100 – 2000 GU
Repeatability	0.2 GU	0.2%
Reproducibility	0.5 GU	0.5% *
Resolution	0.1 GU
Measurement Area	6mm x 6.4mm
Standards	ISO 2813 \| ASTM D523 \| ISO 7668 \| ASTM D2457 \| DIN 67530 \| JIS Z 8741

60° Gloss
Range	0 – 10 GU	10 – 100 GU	100 – 1000 GU
Repeatability	0.1 GU	0.2 GU	0.2%
Reproducibility	0.2 GU	0.5 GU	0.5% *
Resolution	0.1 GU
Measurement Area	6mm x 12mm
Standards	ISO 2813 \| ASTM D523 \| ISO 7668 \| ASTM D2457 \| DIN 67530 \| JIS Z 8741

85° Gloss
Range	0 – 100 GU	100 – 199 GU
Repeatability	0.2 GU	0.2%
Reproducibility	0.5 GU	0.5% *
Resolution	0.1 GU
Measurement Area	4.4mm x 44mm
Standards	ISO 2813 \| ASTM D523 \| ISO 7668 \| ASTM D2457 \| DIN 67530 \| JIS Z 8741

_{* A mirror gloss calibration standard is required to achieve this reproducibility}

Haze
Range	0 – 500 Log HU
Repeatability	1 Log HU
Reproducibility	10 Log HU
Resolution	0.1 Log HU
Measurement Area	6mm x 6.4mm
Standards	ASTM E430 \| ASTM D4039

	RSpec	DOI	RIQ
Range	0 – 2000 GU	0 – 100 GU	0 – 100 GU
Repeatability	0.2%	0.2 Log HU	0.2 Log HU
Reproducibility	0.5%	0.5 Log HU	0.5 Log HU
Resolution	0.1
Measurement Area	6mm x 6.4mm
Standards	Rhopoint	ASTM E430	Rhopoint

Instrument

Instrument Information
Battery Type	Rechargeable lithium ion
Operation Time	17+ hours
Readings per Charge	20,000+
Memory	8MB, 2,000 readings
Operating Temperature	15°C – 40°C (60°F – 104°F)
Operating Humidty	Up to 85% (non condensing)
Commodity Code	9027 5000

Dimension & Weights
Dimensions	140mm (H) x 50mm (W) x 65mm (D)
Instrument Weight	390g
Packed Weight	1.75kg
Packed Dimensions	360mm (H) x 290mm (W) x 140mm (D)

Included Accessories
Certificates:	Instrument calibration certificate Tile calibration certificate
Cables:	USB data & mains cable Wrsit strap
USB Containing:	Instruction manual Bluetooth data app Example Excel spreadsheets Novo-Gloss Multi Gauge software Instructional videos
Calibration Tile	High gloss calibration tile with cleaning cloth
Sample Positioning Templates
Quick Start Guide

Order Codes
Rhopoint IQ 20/60	A6000-013
Rhopoint IQ 20/60/85	A6000-011
