TES-AVM301/AVM303 Anemometer

AVM301 / AVM303 Anemometer is a sensitive and accurate device for air velocity measurement in HVAC, industrial, and environmental applications. It combines ease of use with precise performance.

  • Measures air velocity with a vane sensor and 1.8 m coiled cable for flexible reach
  • Ergonomic design with large 4-digit LCD display for clear readings
  • Features Hold, Max, Min, and Average functions, with low power consumption
  • AVM303 model supports PC connectivity via USB for data analysis and reporting

Description

The AVM301 / AVM303 Anemometer is a sensitive and reliable instrument designed for accurate air velocity measurement in HVAC systems, industrial ventilation, and environmental monitoring applications. Combining precision performance with a user-friendly design, it is well suited for both field technicians and maintenance professionals.

Equipped with a vane-type air velocity sensor and a 1.8-meter coiled cable, the anemometer offers flexible reach and convenient measurement in hard-to-access areas. Its ergonomic handheld design and large 4-digit LCD display ensure clear visibility and comfortable operation during extended use.

Features

  • Sensitive and Accurate
  • Ergonomic and easy-to-use design
  • Large 4 digits LCD (Liquid Crystal Display)
  • 1.8 meters coiled cable and mounting nutfor long extension
  • Low power consumption
  • Hold/Max/Min/Ave functions
  • Built-in low battery indicator
  • Smart Auto-Power-Off (10 minutes)
  • Software and USB cable for working withPC (AVM-303)

Specifications

Mounting Nut 1/4″ x 20
Operating Temperature Meter:0 c ~ 50 c (32 F-122 F)

Vane: 0 c ~ 60 c (32 F-140 F)

Operating Humidity Less than 80% RH
Operating Pressure 500 mB – 2 Bar
Storage Temperature -40 C ~ 60 C (-40 F ~ 140 F)
Power Consumption Approx 6 mA
Battery Type 1.5V AA batteries x 2
Battery Life 200 hours (for 2000mA-hrs battery)
Dimension Meter: 78 x 130 x 40 mm Vane: 66 x 132 x 29.2 mm
Weight 250g (battery included)
Accessories Carrying case x1 Users manual x1 1.5V Battery x2 USB cable (AVM-303) Software CD (AVM-303)

Software Users Manual (AVM-303)
