Description
Specifications:
Immersion Viscosity Cup Type TA
| Cup | Titanium anodized aluminum, 100cc |
| Nozzle | Stainless steel, fixed |
| Handle | Stainless steel |
| Comp with | DIN 53211(No.4) |
| Weight | 176 – 179 g* |
| Cup height | 74mm |
| Max width | 63mm |
| Total height | 250mm |
Immersion Viscosity Cup Type TFR
| Cup | Stainless steel, 100cc |
| Nozzle | Stainless steel, fixed |
| Handle | Stainless steel |
| Comp with | DIN 53211(No.4) |
| Weight | 447 – 450 g * |
| Cup height | 74mm |
| Max width | 63mm |
| Total height | 250mm |
ORDERING INFORMATION
Art. No. VF2071
TQC Viscosity Cup Immersion (Similar to DIN 53211)
Type: made of titanium anodised aluminum, with fixed nozzle orifice Ø 2 mm
Art. No. VF2072
TQC Viscosity Cup Immersion (Similar to DIN 53211)
Type: made of titanium anodised aluminum, with fixed nozzle orifice Ø 3 mm
Art. No. VF2073
TQC Viscosity Cup DIN 53211 Immersion
Type: made of titanium anodised aluminum, with fixed nozzle orifice Ø 4 mm
Optional: possible to certify by calibration with certified oils
Art. No. VF2074
TQC Viscosity Cup Immersion (Similar to DIN 53211)
Type: made of titanium anodised aluminum, with fixed nozzle orifice Ø 5 mm
Art. No. VF2075
TQC Viscosity Cup Immersion (Similar to DIN 53211)
Type: made of titanium anodised aluminum, with fixed nozzle orifice Ø 6 mm
Art. No. VF2077
TQC Viscosity Cup Immersion (Similar to DIN 53211) Type: made of titanium anodised aluminum, with fixed nozzle, orifice Ø 8 mm
Art. No. VF2213
TQC Viscosity Cup Immersion (Similar to DIN 53211)
Type: made of stainless steel, with fixed nozzle orifice Ø 2 mm
Art. No. VF2215
TQC Viscosity Cup DIN 53211 Immersion
Type: made of stainless steel, with fixed nozzle orifice Ø 4 mm
Optional: possible to certify by calibration with certified oils
Art. No. VF2216
TQC Viscosity Cup Immersion (Similar to DIN 53211)
Type: made of stainless steel, with fixed nozzle orifice Ø 5 mm
Art. No. VF2217
TQC Viscosity Cup Immersion (Similar to DIN 53211)
Type: made of stainless steel, with fixed nozzle orifice Ø 6 mm
