Thickness & Coating Measurement Rental
Obsnap offers rental of professional coating and ultrasonic thickness gauges for precise, non-destructive measurement of coatings and material thickness on metals, plastics, composites, and glass.
Rental Services / Thickness & Coating Measurement
Ultrasonic Thickness Gauge Rental (TIME® 2110)
Model: TIME® 2110
Type: Portable Ultrasonic Thickness Gauge
Purpose: Measures wall and material thickness using ultrasonic pulse-echo technology—ideal for corrosion checks, pipeline inspection, and general non-destructive testing.
Ideal For: Marine and shipbuilding, pipeline maintenance, chemical tanks, manufacturing QC, and structural inspections.
| Parameter | Specification |
|---|---|
| Measuring Range | 1.2 mm – 225.0 mm (steel, with standard 5 MHz probe) |
| Resolution | 0.1 mm (TIME 2110) / 0.01 mm (TIME 2113) |
| Accuracy | ±(1%H + 0.1 mm) |
| Sound Velocity Range | 1000 – 9999 m/s |
| Display | 4-digit LCD |
| Memory | Stores last 10 readings |
| Calibration | Zero-point calibration and sound velocity adjustment |
| Power Supply | 2 × AAA batteries (1.5 V) |
| Battery Life | Over 100 hours continuous use |
| Dimensions | 124 × 68 × 27 mm |
| Weight | Approx. 140 g |
| Operating Temperature | 0 °C – 40 °C |
| Optional Probes | 5PΦ10 (1.2–225 mm), SZ2.5P (3–300 mm), 7PΦ6 (0.75–60 mm) |
| Feature | Description |
|---|---|
| Automatic Compensation | Software correction for probe non-linearity ensures precise readings. |
| Zero-Point Calibration | Easy calibration with reference block to maintain accuracy. |
| Coupling Indicator | Visual prompt ensures proper probe contact during measurement. |
| Material Velocity Setting | Adjustable velocity enables testing across metals, plastics, and glass. |
| Dual Unit Display | Readings switchable between mm and inch formats. |
| Data Retention | Retains last 10 measurements even after shutdown. |
| Low Battery & Auto Power-Off | Energy-saving design for extended field operation. |
| Compact & Lightweight | Designed for handheld use in confined or vertical spaces. |
Rental Inclusions & Support
Rental Periods
Calibrated device + test block
Cost Efficiency
No capex; avoid maintenance or calibration overhead
Support Package
Includes technical support and optional training
